Cisco C1200-8FP-2G 8 Port Gigabit PoE+ 2x1G SFP Yönetilebilir Switch

ModelC1200-8FP-2G

Cisco C1200-8FP-2G, 8 portlu 10/100 Mbps bir PoE switch'tir. PoE portları IP kamera, access point ve IP telefon gibi cihazları tek ağ kablosu üzerinden besler; toplam PoE bütçesi 120 W. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.

Port hızı: Fast Ethernet
PoE: PoE
Port sayısı: 8 port

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

8 x Gigabit port
PoE+ destekli portlar, 120W PoE bütçesi
2x1G SFP uplink
8x 10/100/1000 PoE+ ports with 120W power budget
2x Gigabit copper/SFP combo ports
Rack-mountable

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Performans 2 satır

İletim Hızı (Mpps, 64 bayt)	14.88
Anahtarlama Kapasitesi (Gbps)	20

PoE 3 satır

PoE Bütçesi	120W
PoE Destekli Port Sayısı	8
PoE Powered Device (PD)	Select compact switch models can work as PoE PDs and be powered by upstream PoE switches; When AC power is connected and functioning correctly, it is preferred over PoE power. The PoE power can function as a backup to the AC power source or be used as the sole power source for the switch

Güç 8 satır

Sistem Güç Tüketimi	110V=14.59W; 220V=14.33W
Güç Tüketimi (with PoE)	110V=145.44W; 220V=141.80W
Heat dissipation (BTU/hr)	496.26
Idle Power	110V=9.75W; 220V=9.59W
Disable port LEDs	LEDs can be manually turned off to save energy
Time-based port operation	Link up or down based on user-defined schedule (when the port is administratively up)
Time-based PoE	PoE power can be on or off based on user-defined schedule to save energy
Perpetual PoE	Provides PoE power to connected powered devices while the device is rebooting

Arayüzler 3 satır

Toplam Port	10x Gigabit Ethernet
RJ-45 Portlar	8x Gigabit Ethernet
Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP])	2x Gigabit Ethernet combo

Teknik Özellikler 3 satır

Paket Tamponu	1.5 MB
Jumbo Frame	Frame sizes up to 9000 bytes. The default MTU is 2000 bytes
MAC Tablosu	8000 addresses

Fiziksel Özellikler 2 satır

Boyutlar	268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)
Ağırlık	1.53 kg (3.37 lb)

Ortam Koşulları 7 satır

Fan Sayısı	Fanless
MTBF at 25°C (hours)	1,706,649
Güç	100 to 240V 50 to 60 Hz, internal, universal: C1200-8FP-2G, C1200-16T-2G, C1200-16P-2G, C1200-24T-4G, C1200-24P-4G, C1200-24FP-4G, C1200-48T-4G, C1200-48P-4G, C1200-24T-4X, C1200-24P-4X, C1200-24FP-4X, C1200-48T-4X, C1200-48P-4X; 100 to 240V 50 to 60 Hz, external: C1200-8T-D, C1200-8T-E-2G, C1200-8P-E-2G
Sertifikalar	UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
Depolama Sıcaklığı	-13° to 158°F (-25° to 70°C)
Çalışma Nemi	10% to 90%, relative, noncondensing
Depolama Nemi	10% to 90%, relative, noncondensing

Sipariş Bilgileri 1 satır

Ürün Tanımı (Üretici)	● 8x 10/100/1000 PoE+ ports with 120W power budget ● 2x Gigabit copper/SFP combo ports ● Rack-mountable

Yazılım Özellikleri 23 satır

Port grouping/link aggregation	Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP); Up to 4 groups; Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad Link Aggregation Group (LAG)
VLAN	Support for up to 255 active VLANs simultaneously; Port-based and 802.1Q tag-based VLANs; Management VLAN; Guest VLAN; Auto Surveillance VLAN (ASV)
Voice VLAN	Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS. Voice Services Discovery Protocol (VSDP) delivers networkwide zero-touch deployment of voice endpoints and call control devices
IPv4 routing	Wire-speed routing of IPv4 packets; Up to 32 static routes and up to 16 IP interfaces
IPv6 routing	Wire-speed routing of IPv6 packets
Layer 3 interface	Configuration of Layer 3 interface on physical port, LAG, VLAN interface, or loopback interface
Classless Interdomain Routing (CIDR)	Support for CIDR
IPv6 RFCs supported	RFC 4443 (which obsoletes RFC 2463): ICMPv6; RFC 4291 (which obsoletes RFC 3513): IPv6 address architecture; RFC 4291: IPv6 addressing architecture; RFC 2460: IPv6 specification; RFC 4861 (which obsoletes RFC 2461): neighbor discovery for IPv6; RFC 4862 (which obsoletes RFC 2462): IPv6 stateless address auto-configuration; RFC 1981: path MTU discovery; RFC 4007: IPv6 scoped address architecture; …
Web user interface	Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS). Supports configuration, wizards, system dashboard, system maintenance, and monitoring; Basic and advanced mode for maximum operational efficiency
IPv4 and IPv6 dual stack	Coexistence of both protocol stacks to ease migration
Port mirroring	Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 4 source ports can be mirrored to one destination port
VLAN mirroring	Traffic from a VLAN can be mirrored to a port for analysis with a network analyzer or RMON probe. Up to 4 source VLANs can be mirrored to one destination port
Smartports	Simplified configuration of QoS and security capabilities
Auto Smartports	Automatically applies the intelligence delivered through the Smartports roles to the port based on the devices discovered over Cisco Discovery Protocol or LLDP-MED. This facilitates zero-touch deployments
Spanning Tree Protocol (STP)	Standard 802.1d spanning tree support; Fast convergence using 802.1w (Rapid Spanning Tree Protocol [RSTP]), enabled by default; Multiple spanning tree instances using 802.1s (MSTP); 8 instances are supported; Per-VLAN Spanning Tree Plus (PVST+); 126 instances are supported; Rapid PVST+ (RPVST+); 126 instances are supported
IGMP querier	Used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router
Head-of-Line (HOL) blocking	HOL blocking prevention
Loopback detection	Provides protection against loops by transmitting loop protocol packets out of ports on which loop protection has been enabled. It operates independently of STP
Dynamic Host Configuration Protocol (DHCP) relay at Layer	Relay of DHCP traffic across IP domains
User Datagram Protocol (UDP) relay	Relay of broadcast information across Layer 3 domains for application discovery or relaying of Bootstrap Protocol (BootP)/DHCP packets
Standartlar	IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad Link Aggregation Control Protocol, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.3 ad LACP, IEEE 802.1D (STP), IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, RFC 768, RFC …
IPv6	IPv6 host mode; IPv6 over Ethernet; Dual IPv6/IPv4 stack; IPv6 Neighbor Discovery (ND); IPv6 stateless address auto-configuration; Path Maximum Transmission Unit (MTU) discovery; Duplicate Address Detection (DAD); ICMP version 6; IPv6 over IPv4 network with Intrasite Automatic Tunnel Addressing Protocol (ISATAP) support
IPv6 QoS	Prioritizes IPv6 packets in hardware

Güvenlik 13 satır

Secure Sensitive Data (SSD)	A mechanism to manage sensitive data (such as passwords, keys, and so on) securely on the switch, populating this data to other devices and a secure auto-configuration. Access to view the sensitive data as plain text or encrypted is provided according to the user-configured access level and the access method of the user
Port security	Ability to lock source MAC addresses to ports and limit the number of learned MAC addresses
Secure Sockets Layer (SSL)	Encrypts all HTTPS traffic, allowing secure access to the browser-based management GUI in the switch
SSH Protocol	SSH is a secure replacement for Telnet traffic. Secure Copy (SCP) also uses SSH. SSH v1 and v2 are supported.
IEEE 802.1X (authenticator role)	RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions
STP loopback guard	Provides additional protection against Layer 2 forwarding loops (STP loops)
Secure Core Technology (SCT)	Ensures that the switch will receive and process management and protocol traffic no matter how much traffic is received
Trustworthy systems	Trustworthy systems provide a highly secure foundation for Cisco products; Run-time defenses (Executable Space Protection [X-Space], Address Space Layout Randomization [ASLR], Built-In Object Size Checking [BOSC])
RADIUS	Supports RADIUS authentication for management access. Switch functions as a client
Storm control	Broadcast, multicast, and unknown unicast
DoS prevention	DoS attack prevention
Multiple user privilege levels in CLI	Level 1, 7, and 15 privilege levels
ACLs	Support for up to 512 rules; Drop or rate limit based on source and destination MAC, VLAN ID, IPv4 or IPv6 address, IPv6 flow label, protocol, port, Differentiated Services Code Point (DSCP)/IP precedence, TCP/UDP source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, IGMP packets, TCP flag; ACL can be applied on both ingress and egress …

Model Özellikleri 5 satır

Konsol Portu	Cisco Standard RJ-45 console and USB Type C port; Not available on C1200-8T-D
USB Portu	USB Type C port on the front panel of the switch for easy file and image management as well as console port
Flash Bellek	512 MB
İşlemci	Dual-core ARM at 1.4 GHz
DRAM	1 GB DDR4

Genel bakış

Cisco C1200-8FP-2G kullanım alanları ve özellikleri.

Cisco Catalyst 1200 serisi C1200-8FP-2G, 8 adet Gigabit port, PoE+ desteği ve 120W PoE bütçesi, 2x1G SFP uplink sunan yönetilebilir katman 2/3 switch'tir.

From connectivity to cloud applications, networking plays a crucial role in every business journey. Reliability, security, and affordability continue to be top of mind, while ongoing management and operations add complexity that takes time and resources.

The Cisco Catalyst ™ 1200 Series Switches are affordable switches designed and built for small and medium-sized businesses. Managed through the Cisco ® Business mobile app or dashboard, the switch portfolio provides a simple and reliable experience.

Öne Çıkan Özellikler

8 x Gigabit port
PoE+ destekli portlar, 120W PoE bütçesi
2x1G SFP uplink
8x 10/100/1000 PoE+ ports with 120W power budget
2x Gigabit copper/SFP combo ports
Rack-mountable

Nerelerde kullanılır?

IP kamera, access point ve IP telefon projelerinde cihazlara tek kablodan enerji ve veri taşır; NVR ile kameralar arasında dağıtım katmanı oluşturur.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Catalyst 1200 Datasheet (EN)PDF · C1200-8FP-2G Catalyst 1200 Datasheet (PDF)PDF · C1200-8FP-2G

Sık sorulanlar

C1200-8FP-2G hakkında kısa yanıtlar.

C1200-8FP-2G IP kamera beslemek için uygun mu?

Evet. PoE portları IP kameraları tek kablo üzerinden besler; toplam PoE bütçesi 120 W olduğundan kamera tüketimlerinin toplamı bu değerin altında kalmalıdır.

C1200-8FP-2G kaç portlu?

C1200-8FP-2G 8 porta sahiptir.

C1200-8FP-2G fiyatı ne kadar?

C1200-8FP-2G için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
