Cisco CBS220-48P-4X 48 Port Gigabit PoE+ 4x10G SFP+ Akıllı Yönetilebilir Switch

ModelCBS220-48P-4X

Cisco CBS220-48P-4X, 48 portlu 10/100 Mbps bir PoE switch'tir. PoE portları IP kamera, access point ve IP telefon gibi cihazları tek ağ kablosu üzerinden besler; toplam PoE bütçesi 382 W. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.

Port hızı: Fast Ethernet
PoE: PoE
Port sayısı: 48 port

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

48 x Gigabit port
PoE+ destekli portlar, 382W PoE bütçesi
4x10G SFP+ uplink
48 10/100/1000 PoE+ ports with 382 W power budget 4 10G SFP+ port

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Performans 2 satır

İletim Hızı in millions of packets per second (mpps; 64-byte packets)	130.94
Anahtarlama Kapasitesi (Gbps)	176

PoE 4 satır

PoE Bütçesi	382W
PoE Destekli Port Sayısı	48
Pre-standard PoE	Support Cisco Pre-Standard PoE
Intelligent PoE power management	Support the granular power negotiation with CDP/LLDP communication with PD devices after IEEE classification

Arayüzler 3 satır

Toplam Port	48 Gigabit Ethernet +; 4 10 Gigabit Ethernet
RJ-45 Portlar	48 Gigabit Ethernet
Uplink Portları	4 10G SFP+

Teknik Özellikler 1 satır

Paket Tamponu	16 Mb

Fiziksel Özellikler 2 satır

Boyutlar	440 x 350 x 44 mm (17.3 x 13.8 x 1.7 in)
Ağırlık	5.36 kg (11.82 lb)

Güç 6 satır

Sistem Güç Tüketimi	110V=54.8W; 220V=55.1W
Güç Tüketimi (with PoE)	110V=482W; 220V=468W
Heat dissipation (BTU/hr)	1,644.65
Disable port LEDs	LEDs can be manually turned off to save on energy.
Time-based PoE	PoE power can be on or off based on user-defined schedule to save energy.
Time-based port operation	Link up or down based on user-defined schedule (when the port is administratively up).

Ortam Koşulları 8 satır

Fan Sayısı	1
Akustik Gürültü	25°C: 35.1 dB
MTBF @ 25°C (hours)	265,589
Güç	100-240 V, 50-60 Hz, Internal: CBS220-16T-2G, CBS220-16P-2G, CBS220-24T-4G, CBS220-24P-4G, CBS220-24FP-4G, CBS220-48T-4G, CBS220-48P-4G, CBS220-24T-4X, CBS220-24P-4X, CBS220-24FP-4X, CBS220-48T-4X, CBS220-48P-4X, CBS220-48FP-4X; 100-240 V, 50-60 Hz, External: CBS220-8T-E-2G, CBS220-8P-E-2G, CBS220-8FP-E-2G
Sertifikalar	UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, C-tick
Depolama Sıcaklığı	–20° C to +70° C
Çalışma Nemi	10% to 90%, relative, noncondensing
Depolama Nemi	10% to 90%, relative, noncondensing

Sipariş Bilgileri 1 satır

Ürün Tanımı (Üretici)	48 10/100/1000 PoE+ ports with 382 W power budget 4 10G SFP+ port

Yazılım Özellikleri 30 satır

MAC Tablosu	Up to 8,192 Media Access Control (MAC) addresses
Port grouping	Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP); Up to 8 groups; Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation; Load balance based on source and destination MAC address, or source and destination MAC/IP
VLAN	Support for up to 256 Virtual Local Area Networks (VLANs) simultaneously; Port-based and 802.1Q tag-based VLANs; Management VLAN; Guest VLAN
Auto voice VLAN	Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS
Q in Q VLAN	VLANs transparently cross a service provider network while isolating traffic among customers
Jumbo Frame	Frame sizes up to 9,216 supported
Automatic Media-Dependent Interface Crossover (MDIX)	Automatically adjusts transmit and receive pairs if an incorrect cable type (crossover or straight-through) is installed.
IPv6 Requests for Comments (RFCs) supported	RFC 4443 (which obsoletes RFC2463) - ICMP version 6; RFC 4291 (which obsoletes RFC 3513) - IPv6 address architecture; RFC 4291 - IPv6 addressing architecture; RFC 2460 - IPv6 specification; RFC 4861 (which obsoletes RFC 2461) - Neighbor discovery for IPv6; RFC 4862 (which obsoletes RFC 2462) - IPv6 stateless address auto-configuration; RFC 1981 - Path MTU discovery; RFC 4007 - IPv6 scoped address …
Web user interface	Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS). Supports configuration, system dashboard, system maintenance, and monitoring
Command-line interface	Scriptable CLI; a full CLI is supported. User privilege levels 1 and 15 are supported for the CLI
IPv4 and IPv6 dual stack	Coexistence of both protocol stacks to ease migration
Port mirroring	Traffic on a port or VLAN can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 8 source ports can be mirrored to one destination port. Four sessions are supported.
Spanning Tree Protocol (STP)	Standard 802.1d Spanning Tree support, enabled by default; Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]); Multiple Spanning Tree instances using 802.1s (MSTP); 16 instances are supported
Head-of-Line (HOL) blocking	HOL blocking prevention
Loopback detection	Loopback detection provides protection against loops by transmitting loop protocol packets out of ports on which loop protection has been enabled. It operates independently of STP.
Priority levels	8 hardware queues per port
Scheduling	Strict priority and Weighted Round-Robin (WRR) queue assignment based on DSCP and class of service (802.1p/CoS)
Class of service	Port-based; 802.1p VLAN priority-based; IPv4/v6 IP precedence, Type of Service (ToS), and DSCP-based; Differentiated Services (DiffServ); classification and re-marking ACLs, trusted QoS
Rate limiting	Ingress policer; egress shaping and rate control; per VLAN, per port, and flow-based
Congestion avoidance	A TCP congestion avoidance algorithm is required to reduce and prevent global TCP loss synchronization.
IGMP querier	IGMP querier is used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router
Standartlar	IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab; 1000BASE-T Gigabit Ethernet, IEEE 802.3ad LACP, IEEE 802.3z Gigabit Ethernet, IEEE; 802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP), IEEE 802.1Q/p VLAN, IEEE; 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE; 802.3af, IEEE 802.3at, RFC 768, Request for Comments (RFC) 783, …
IPv6	IPv6 host mode; IPv6 over Ethernet; IPv6/IPv4 Dual Stack; IPv6 neighbor and router discovery (ND); IPv6 stateless address auto-configuration; Path Maximum Transmission Unit (MTU) discovery; Duplicate Address Detection (DAD); ICMP version 6
IPv6 ACL	Drop or rate limit IPv6 packets in hardware
IPv6 QoS	Prioritize IPv6 packets in hardware
Multicast Listener Discovery (MLD v1/2) Snooping	Deliver IPv6 multicast packets only to the required receivers
IPv6 applications	Web/SSL, Telnet server/SSH, DHCP Client, DHCP Autoconfig, Cisco Discovery Protocol (CDP), Link Layer Discovery Protocol (LLDP)
Cisco Business Dashboard	Support direct management with Cisco Business Dashboard and mobile app. Eliminates the need to set up a separate hardware or virtual machine for the Cisco Business Dashboard Probe on site.
Cisco Business mobile app	Mobile app for Cisco Business Switch and Wireless products. Helps to set up a local network in minutes and provide easy management at your fingertips.
Cisco Network Plug and Play (PnP) agent	The Cisco Network Plug and Play solution provides a simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or for provisioning updates to an existing network. The solution provides a unified approach to provision Cisco routers, switches, and wireless devices with a zero touch deployment experience.; Supports Cisco PnP Connect

Güvenlik 11 satır

Port security	Creates the ability to lock source MAC addresses to ports; limits the number of learned MAC addresses
MAC address filtering	Supported
ACLs	Drop or rate limit based on source and destination MAC, VLAN ID or IP address, protocol, port, Differentiated Services Code Point (DSCP)/IP precedence, Transmission Control Protocol (TCP)/ User Datagram Protocol (UDP) source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, Internet Group Management Protocol (IGMP) packets, TCP flag; Support up to 512 rules
IEEE 802.1X (authenticator role)	802.1X: Remote Authentication Dial-in User Service (RADIUS) authentication; guest VLAN; Single-host, multiple-host, and multisession mode
RADIUS, TACACS+	Supports RADIUS and Terminal Access Controller Access Control System (TACACS) authentication; switch functions as a client
Storm control	Broadcast, multicast, and unknown unicast
DoS protection	DOS attack prevention
STP Bridge Protocol Data Unit (BPDU) Guard	This security mechanism protects the network from invalid configurations. A port enabled for BPDU Guard is shut down if a BPDU message is received on that port.
Spanning Tree Loop Guard	This feature provides additional protection against Layer 2 forwarding loops (STP loops).
Secure Shell (SSH) Protocol	SSH is a secure replacement for Telnet traffic. SCP also uses SSH. SSH v1 and v2 are supported.
Secure Sockets Layer (SSL)	SSL support: Encrypts all HTTPS traffic, allowing highly secure access to the browser-based management GUI in the switch

Model Özellikleri 2 satır

Flash Bellek	64 MB
CPU memory	256 MB

Genel bakış

Cisco CBS220-48P-4X kullanım alanları ve özellikleri.

Cisco Business 220 serisi CBS220-48P-4X, 48 adet Gigabit port, PoE+ desteği ve 382W PoE bütçesi, 4x10G SFP+ uplink sunan akıllı yönetilebilir katman 2/3 switch'tir.

From connectivity to cloud applications, networking plays a crucial role in every business journey. Reliability, security, and affordability continue to be priorities, while ongoing management and operations add additional complexity that takes time and resources.

Cisco Business is a portfolio of affordable wireless access points, switches, and routers designed and built for Small Business. Managed through Cisco Business Dashboard and mobile app, the portfolio provides a simple and reliable experience. Cisco Business Dashboard simplifies traditional challenges in deploying and managing business networks by automating the deployment, monitoring, and lifecycle management of the network.

Öne Çıkan Özellikler

48 x Gigabit port
PoE+ destekli portlar, 382W PoE bütçesi
4x10G SFP+ uplink
48 10/100/1000 PoE+ ports with 382 W power budget 4 10G SFP+ port

Nerelerde kullanılır?

IP kamera, access point ve IP telefon projelerinde cihazlara tek kablodan enerji ve veri taşır; NVR ile kameralar arasında dağıtım katmanı oluşturur.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Cisco Business 220 Datasheet (EN)PDF · CBS220-48P-4X Cisco Business 220 Datasheet (PDF)PDF · CBS220-48P-4X

Sık sorulanlar

CBS220-48P-4X hakkında kısa yanıtlar.

CBS220-48P-4X IP kamera beslemek için uygun mu?

Evet. PoE portları IP kameraları tek kablo üzerinden besler; toplam PoE bütçesi 382 W olduğundan kamera tüketimlerinin toplamı bu değerin altında kalmalıdır.

CBS220-48P-4X kaç portlu?

CBS220-48P-4X 48 porta sahiptir.

CBS220-48P-4X fiyatı ne kadar?

CBS220-48P-4X için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
