IP Kamera DeepinView

Hikvision DS-2CD6445G3-C2W 4 MP DeepinView IP Kamera

ModelDS-2CD6445G3-C2W

Hikvision DS-2CD6445G3-C2W, 4 MP çözünürlüklü, 2 mm lensli bir IP kameradır. DeepinView teknolojisiyle insan ve araç hareketlerini ayırt ederek yanlış alarmları azaltır.

Sinyal tipi: IP
Çözünürlük: 4 MP
Lens: 2 mm
Teknoloji: DeepinView

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

High quality imaging with 4 MP resolution
Clear imaging against strong back light due to WDR technology
Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
Supports 4 Tops computing power, 150 MB system memory, 2150 MB smart RAM, and 1 GB eMMC storage for sharing resources
Audio and alarm interface available

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Kamera 4 satır

Görüntü Sensörü	1/2.7" Progressive Scan CMOS
Maks. Çözünürlük	2688 × 1520
Min. Aydınlatma	Color: 0.005 Lux @ (F1.2, AGC ON)
Enstantane Süresi	1 s to 1/100,000 s

Lens 5 satır

Odak Uzaklığı ve Görüş Açısı	L30 model: 2 mm, Horizontal FOV:128°, Vertical FOV:75°, Diagonal FOV:147°; 2.8 mm, Horizontal FOV:104°, Vertical FOV:58°, Diagonal FOV:122°; 4 mm, Horizontal FOV:78°, Vertical FOV:43°, Diagonal FOV:93°
Lens Yuvası	L30: M12
İris Tipi	Fixed
Diyafram	F2.0
Lens seçenekleri	2.8 mm, 4 mm

Piksel Yoğunluğu (DORI) 1 satır

OODPCVS	2 mm: Overview: 56.8 m, Outline: 28.4 m, Discern: 14.2 m, Perceive: 9.1 m, Characterize: 4.5 m, Validate: 2.3 m, Scrutinize: 0.8 m.; 2.8 mm: Overview: 74.8 m, Outline: 37.4 m, Discern: 18.7 m, Perceive: 12 m, Characterize: 6 m, Validate: 3 m, Scrutinize: 1 m.; 4 mm: Overview: 99.5 m, Outline: 49.8 m, Discern: 24.9 m, Perceive: 15.9 m, Characterize: 8 m, Validate: 4 m, Scrutinize: 1.3 m.; The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN

OODPCVS

2 mm: Overview: 56.8 m, Outline: 28.4 m, Discern: 14.2 m, Perceive: 9.1 m, Characterize: 4.5 m, Validate: 2.3 m, Scrutinize: 0.8 m.; 2.8 mm: Overview: 74.8 m, Outline: 37.4 m, Discern: 18.7 m, Perceive: 12 m, Characterize: 6 m, Validate: 3 m, Scrutinize: 1 m.; 4 mm: Overview: 99.5 m, Outline: 49.8 m, Discern: 24.9 m, Perceive: 15.9 m, Characterize: 8 m, Validate: 4 m, Scrutinize: 1.3 m.; The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN

HEOP (Açık Platform) 4 satır

Açık Kaynaklar	Memory: 150 MB; Smart RAM: 2150 MB; eMMC: 1 GB
İşlem Gücü	4 TOPS
Derin Öğrenme Yapısı	Caffe, PyTorch, TensorFlow
Programlama Dili	C, C++

AI Açık Platform 1 satır

Model Özellikleri	1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model).; 2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification).; (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ra

Model Özellikleri

1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model).; 2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification).; (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ra

Video 10 satır

Ana Akış	50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720); 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Alt Akış	50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480)
Üçüncü Akış	50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480); 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Sıkıştırma	Main stream: H.264/H.265+/H.264+/H.265; Sub-stream: H.264/MJPEG/H.265; Third stream: H.264/H.265
H.264 Tipi	Baseline Profile, Main Profile, High Profile
H.265 Tipi	Main Profile
Bit Hızı Kontrolü	CBR, VBR
Ölçeklenebilir Video Kodlama (SVC)	H.264 and H.265 encoding
İlgi Bölgesi (ROI)	8 fixed regions for each stream
Hedef Kırpma	Evet

Ses 5 satır

Ses Tipi	Mono sound
Ses Sıkıştırma	G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Ses Bit Hızı	64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
Ses Örnekleme Hızı	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Ortam Gürültüsü Filtreleme	Evet

Ağ 8 satır

Protokoller	WebSockets, NTP, DHCP, WebSocket, UDP, RTSP, ICMP, IPv6, TCP/IP, IGMP, QoS, HTTPS, IPv4, HTTP, SSL/TLS, DNS, FTP, SFTP, RTP
Eşzamanlı Canlı İzleme	Up to 20 channels
API	Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP, EZVIZ
Kullanıcı/Host	Up to 32 users; 3 user levels: administrator, operator, and user
Ağ Depolama	NAS (NFS, SMB/CIFS)
İstemci	iVMS-4200, Hik-Connect
Güvenlik	Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Web Tarayıcı	Plug-in required live view: IE11; Plug-in free live view: Safari 12+; Local service: Chrome 57.0+, Firefox 52.0+

Wi-Fi 4 satır

Şifreleme Modu	With -W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK, WPS
Wi-Fi Protokolü	With -W: IEEE802.11a, IEEE802.11b, IEEE802.11ax, IEEE802.11g, IEEE802.11n, IEEE802.11ac
Frekans Aralığı	With -W: 2.4 GHz to 2.4835 GHz; 5.150 GHz to 5.850 GHz;
Kanal Bant Genişliği	With -W: 20MHz,40MHz

Görüntü 6 satır

Görüntü Parametresi Geçişi	Evet
Görüntü Ayarları	gain, saturation, brightness, sharpness, white balance, contrast, adjustable by client software or web browser
Geniş Dinamik Aralık (WDR)	Digital WDR
Görüntü İyileştirme	BLC, HLC,3D DNR
Mahremiyet Maskesi	Evet
Görüntü Bindirme	LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Arayüz 8 satır

Ethernet Arayüzü	1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Video Çıkışı	1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Dahili Depolama	Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1024 GB
Ses	1 input (line in), 1 output (line out)
Alarm	2 input, 1 output (max. 12 VDC, 30 mA)
RS-485	1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Tuşu	Evet
Güç Çıkışı	12 VDC, max. 100 mA

Olay 3 satır

Temel Olaylar	Motion detection
Akıllı Olaylar	Scene change detection, audio exception detection, defocus detection; Face detection
Bağlantı (Linkage)	audible warning, Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture

Derin Öğrenme Fonksiyonları 5 satır

Yüz Yakalama	Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second; Supports swing left and right from -70° to 70°, tilt up and down from -50° to 50°; Uploads face with background and closed-up face pictures; Supports best shot and quick shot for capture mode; Supports dynamic mosaic mask; Gets 7 face features
Yüz Karşılaştırma	Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total; Supports face library encryption
Kişi Sayma	Supports Multi-Dimension People Counting; Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.); Supports real-time uploading and uploading by statistic cycle; Supports generating daily, weekly, monthly or annually reports; Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within
Kuyruk Yönetimi	Supports up to 8 detection regions, and independent arming schedule and linkage method Supports 2 detection modes: regional people queuing-up, waiting time detection Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue Supports raw data export for further analysis Supports real-time data uploading and scheduled data uploading Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than th
Gaze Detection	Max. detection distance: 5 m; Max. detection target number: 30; Supports 1 rule area(s); Supports 4 shield region(s)

Genel 11 satır

Güç	12 VDC ± 20%, 0.92 A, max. 11 W; PoE: IEEE 802.3af, Class 3, max. 12.9 W
Malzeme	Main body: Aluminum Alloy
Boyutlar	135 mm × 108 mm × 30.4 mm (5.32" × 4.25" × 1.2")
Paket Boyutları	252 mm × 160 mm × 95 mm (9.92" × 6.3" × 3.74")
Ağırlık	Approx. 460 g (1.01 lb.)
Paketli Ağırlık	Approx. 1100 g (2.43 lb.)
Depolama Koşulları	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Başlangıç ve Çalışma Koşulları	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Dil	33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Genel Fonksiyonlar	Heartbeat, mirror, password protection, one-key reset
Lens Kablosu Uzunluğu	2 and 8 m (6.6 and 26.2 ft.)

Onaylar 3 satır

EMC	FCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014; RCM: AS/NZS CISPR 32: 2015; IC: ICES-003: Issue 7; KC: KN32: 2015, KN35: 2015
Güvenlik	CB: IEC 62368-1: 2014+A11; CE-LVD: EN 62368-1: 2014/A11: 2017; BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005; LOA: IEC/EN 60950-1
Çevre	CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006

Genel bakış

Hikvision DS-2CD6445G3-C2W kullanım alanları ve özellikleri.

Hikvision DS-2CD6445G3-C2W, 4 MP çözünürlük ve 2.8 mm / 4 mm lens seçenekleri sunan bir IP Kamera modelidir. DeepinView serisi gelişmiş derin öğrenme analizleri sunar.

4MP DeepinView Separated Network Camera

High quality imaging with 4 MP resolution
Clear imaging against strong back light due to WDR technology
Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
Supports 4 Tops computing power, 150 MB system memory, 2150 MB smart RAM, and 1 GB eMMC storage for sharing resources
Audio and alarm interface available

Kurulum ve uyumluluk

DS-2CD6445G3-C2W PoE destekli bir NVR veya PoE switch üzerinden tek ağ kablosuyla beslenebilir; ONVIF desteği olan kayıt cihazlarıyla da çalışır. Uzaktan izleme için Hik-Connect mobil uygulaması kullanılır.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

DatasheetPDF · DS-2CD6445G3-C2W Hızlı Başlangıç KılavuzuPDF · DS-2CD6445G3-C2W Kullanım KılavuzuPDF · DS-2CD6445G3-C2W Firmware (V5.9.0_260723) - indirme sayfasıPDF · DS-2CD6445G3-C2W

Sık sorulanlar

DS-2CD6445G3-C2W hakkında kısa yanıtlar.

DS-2CD6445G3-C2W hangi kayıt cihazıyla çalışır?

IP kamera olduğu için NVR kayıt cihazlarıyla çalışır. Tüm akıllı özellikler için Hikvision NVR, temel kayıt için ONVIF destekli NVR'lar kullanılabilir.

DS-2CD6445G3-C2W kaç megapiksel?

DS-2CD6445G3-C2W 4 MP çözünürlüğe sahiptir ve 2 mm lens kullanır.

DS-2CD6445G3-C2W cep telefonundan nasıl izlenir?

Hikvision cihazları Hik-Connect mobil uygulamasıyla izlenir. Cihaz uygulamaya eklendikten sonra canlı izleme, kayıt izleme ve bildirim alma yapılabilir.

DS-2CD6445G3-C2W fiyatı ne kadar?

DS-2CD6445G3-C2W için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
