Juniper EX5200-24T 24 Port Yönetilebilir Switch

ModelEX5200-24T

Juniper EX5200-24T, 24 portlu gigabit bir yönetilebilir switch'tir. PoE portları IP kamera, access point ve IP telefon gibi cihazları tek ağ kablosu üzerinden besler. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.

Port hızı: Gigabit
PoE: PoE
Port sayısı: 24 port

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

Wi-Fi 7-ready switches with PoE models that support IEEE 802.3bt Class 8 up to 90W per port and up to 3500W aggregate PoE budget on the 48-port model
End-to-end encryption using MACsec AES-256 encryption helps protect switch-to-switch and switch-to-host traffic while preserving network visibility and policy enforcement
High-density multigigabit access with 24- and 48-port models delivers 100 MbE to 10 GbE connectivity for WiFi, IP communications, smart buildings, and IoT endpoints
EVPN-VXLAN enables scalable Layer 2 and Layer 3 overlays with standardsbased group-based policy for macro and micro segmentation
Redundant hot-swappable power supplies and fans, fast PoE, perpetual PoE, nonstop bridging, active routing, and graceful failover help maintain uptime
Up to 10 switches can operate as a single logical system with 400 Gbps full-duplex virtual chassis bandwidth

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Genel 1 satır

Ürün Adı (Üretici)	HPE Networking EX5200 Switch Series EX5200-24T

Seri Özellikleri 13 satır

Güç Tüketimi	Depending on the model
Giriş Gerilimi	100-120V/200-240V
Portlar	Up to 48x 100M/1G/2.5G/5G/10G multigigabit ports depending on the model 2x QSFP28 ports for uplink or virtual chassis Optional 2x 100G or 8x 25G port uplink modules available and sold separately
Anahtarlama Kapasitesi	EX5200-24MP/24T: 640 Gbps (unidirectional)/ 1280 Gbps (bidirectional) EX5200-48MP/48T: 880 Gbps (unidirectional)/ 1760 Gbps (bidirectional)
Stacking capabilities	Up to 10 member virtual chassis
Veri Hızı	EX5200-24MP/T 952.38Mpps EX5200-48MP/T 1309.52 Mpps
Memory and processor	8 GB RAM 2.2 GHz Quad-Core Intel® x86 CPU
Güç Kaynağı	Depending on model
PoE capability	90W per port Up to 3500W PoE budget depending on model
Çalışma Sıcaklığı	32° to 113° F (0° to 45°C)
Management features	Command-Line Interface (CLI) HPE Mist
Garanti	Enhanced limited lifetime warranty (ELLW)
Fan	Up to 3x Air Flow Out (AFO) fans depending on model

Genel bakış

Juniper EX5200-24T kullanım alanları ve özellikleri.

The HPE Networking EX5200 Switch Series is built for the AI era, delivering secure, high-performance campus access for modern PoE and non-PoE deployments. Purpose-built to support growing bandwidth, power, and operational demands at the edge, it combines flexible 100M/1G/2.5G/5G/10GbE multigigabit access, IEEE 802.3bt PoE++ power, endto-end MACsec AES-256 encryption, standards-based EVPN-VXLAN campus fabrics, and AI-driven operations through HPE Mist Wired Assurance.

The series includes four compact 1U access switch models with 10 GbEcapable copper ports, modular uplink options, and dedicated high-speed virtual chassis/uplink ports for scalable, resilient campus designs. Models include the EX5200-48MP with 48 PoE ports and up to a 3500W PoE budget, the EX5200-24MP with 24 PoE ports and up to a 2160W PoE budget, the EX5200-48T with 48 non-PoE ports, and the EX5200-24T with 24 non-PoE ports. Together, they help enterprises modernize access networks with flexibility and security.

Cloud-based management with HPE Mist Networking Wired Assurance enables EX5200 switches to be quickly onboarded (day 0), provisioned (day 1), and managed (day 2+) from the cloud.

AI-assisted troubleshooting with HPE Marvis actions helps identify issues such as missing VLANs, DHCP failures, authentication issues, bad cables, port-negotiation mismatches, and L2 loops.

Wi-Fi 7-ready switches with PoE models that support IEEE 802.3bt Class 8 up to 90W per port and up to 3500W aggregate PoE budget on the 48-port model
End-to-end encryption using MACsec AES-256 encryption helps protect switch-to-switch and switch-to-host traffic while preserving network visibility and policy enforcement
High-density multigigabit access with 24- and 48-port models delivers 100 MbE to 10 GbE connectivity for WiFi, IP communications, smart buildings, and IoT endpoints
EVPN-VXLAN enables scalable Layer 2 and Layer 3 overlays with standardsbased group-based policy for macro and micro segmentation
Redundant hot-swappable power supplies and fans, fast PoE, perpetual PoE, nonstop bridging, active routing, and graceful failover help maintain uptime
Up to 10 switches can operate as a single logical system with 400 Gbps full-duplex virtual chassis bandwidth

Nerelerde kullanılır?

Kurumsal ağlarda VLAN ile kamera, misafir ve ofis trafiğini ayırmak, uplink ve omurga bağlantılarını yönetmek için kullanılır.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet - HPE Networking EX5200 Switch SeriesPDF · EX5200-24T

Sık sorulanlar

EX5200-24T hakkında kısa yanıtlar.

EX5200-24T IP kamera beslemek için uygun mu?

Evet. PoE portları IP kameraları tek kablo üzerinden besler. Toplam kamera tüketiminin switch'in PoE bütçesini aşmaması gerekir.

EX5200-24T kaç portlu?

EX5200-24T 24 porta sahiptir.

EX5200-24T fiyatı ne kadar?

EX5200-24T için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
