Mito AZ 300M 100V 5 Bölgeli Mikser Amfi

4 balanced combined mic inputs of 1/4” phone jack and XLR type with separate gain control and phantom power switch 2 dual RCA line inputs, TEl and EMC input

5 levels of input priority from high to low: EMC input, remote paging console, Mic1, siren/chime over other inputs.

• The AZ Series 5 zone mixer amplifiers are 3U amplifier featuring 70V
• 100V and 4-16 Ω speaker output &4 universal combined mic inputs of
• 1/4” phone jack and XLR type. 5 line inputs by dual RCA type are also
• Provided. The uniqueness of this amplifier is that the 2 zone outputs
• With separate volume control, which provide flexible zone control. Each
• 6 inputs are equipped with bass/treble tone controls.
• Master Mic 1-4, line 1-2 volume control& 6 separate treble/bass tone
• Control for eazch input are provided, along with mic 1 of priortiy over
• Other inputs. Each channel input with separate treble and bass control.
• Built in sire for fire alarm system, EMC input, built in chime, 2/4 tone
• Chime selector, chime remote trigger. The TEL input could be used as
• Telephone paging system over PA system.
• The REC output for tape recorder and PRE output, AMP input for
• Adding extra signal processor like mixer, graphic equalizer.
• Complete protection includes short circuit and thermal protection
• Current limiter and overloading.
• 7 inputs 5 zone mixer amplifier
• Rack mount amplifier in 3U type
• Rated power output 120W, 240W, 300W and 500W
• 70V, 100V and 4-16 Ω speaker terminals
• 5 zone 100V output and all zone outputs
• Each zone speaker output with separate volume control
• Remote paging console MIC 05 for zone paging control
• Built in siren and 2/4 tone chime
• Volume control over master, Mic1-4, Line 1-2, chime, siren, all zone output and each 2 zone output
• Tel input and remote paging mic
• REC output for tape recorder
• PRE Output and AMP input for extra signal processor
• AC 110V or 220V and DC 24V operation
• MIXER AMPLIFIER with ZONE
• PAGING SYSTEMS

Nerelerde kullanılır?

Okul, cami, fabrika, otel ve AVM seslendirme sistemlerinde hoparlör hatlarını besler; bölge seçimi ile alanlara ayrı anons ve müzik yayını yapılabilir.

Tüm özellikler

• The AZ Series 5 zone mixer amplifiers are 3U amplifier featuring 70V
• 100V and 4-16 Ω speaker output &4 universal combined mic inputs of
• 1/4” phone jack and XLR type. 5 line inputs by dual RCA type are also
• Provided. The uniqueness of this amplifier is that the 2 zone outputs
• With separate volume control, which provide flexible zone control. Each
• 6 inputs are equipped with bass/treble tone controls.
• Master Mic 1-4, line 1-2 volume control& 6 separate treble/bass tone
• Control for eazch input are provided, along with mic 1 of priortiy over
• Other inputs. Each channel input with separate treble and bass control.
• Built in sire for fire alarm system, EMC input, built in chime, 2/4 tone
• Chime selector, chime remote trigger. The TEL input could be used as
• Telephone paging system over PA system.
• The REC output for tape recorder and PRE output, AMP input for
• Adding extra signal processor like mixer, graphic equalizer.
• Complete protection includes short circuit and thermal protection
• Current limiter and overloading.
• 7 inputs 5 zone mixer amplifier
• Rack mount amplifier in 3U type
• Rated power output 120W, 240W, 300W and 500W
• 70V, 100V and 4-16 Ω speaker terminals
• 5 zone 100V output and all zone outputs
• Each zone speaker output with separate volume control
• Remote paging console MIC 05 for zone paging control
• Built in siren and 2/4 tone chime
• Volume control over master, Mic1-4, Line 1-2, chime, siren, all zone output and each 2 zone output
