RUIJIE · RG-AM5832-SF-P Ruijie RG-AM5832-SF-P Optik Master Tavan Tipi Access Point

Ruijie RG-AM5832-SF-P Optik Master Tavan Tipi Access Point

Q: RG-AM5832-SF-P fiyatı ne kadar?

RG-AM5832-SF-P için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.

ModelRG-AM5832-SF-P

Ruijie RG-AM5832-SF-P access point: Hybrid cables, simplifying optical network deployment, Rich port options to adapt to various APs and achieve flexible service expansion, No license required for identifying and connecting to SOE micro APs, WIS digital twin network for superior network O&M effi.

Hybrid cables, simplifying optical network deployment
Rich port options to adapt to various APs and achieve flexible service expansion
No license required for identifying and connecting to SOE micro APs
WIS digital twin network for superior network O&M effictiency

Fiyat ve stok bilgisi alınAynı iş günü dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

Türkiye geneli sevkiyat

Kurulum ve teknik destek

Genel bakış

Ruijie RG-AM5832-SF-P özellikleri ve kullanım alanları.

Recommended for deployment in schools, hotels, medical care, office, production workshops, etc.

RG-AM5832-SF-P SOE Master AP

Uplink: 8 x 25GE SFP28 ports or 2 x 40GE QSFP+ ports, on-demand selection of cards to match the backbone network, offering flexible networking options. Downlink: All 10GE SFP+ ports, accommodating 24 APs, supporting hybrid cables, and enabling high-performance, easily scalable optical network access for all scenarios

Selection by Backbone Network

Uplink 40GE card

Uplink 25GE card

Hybrid Cables, Simplifying Optical Network Deployment

The optical-electrical parallel design allows the hybrid cable to be connected to APs, achieving data transmission over 1100 m (0.68 miles) with high bandwidth and PoE power supply delivered directly to the APs. This approach reduces the need for the ELV room on each floor, simplifies network cabling, and eliminates the requirement for local high-voltage reconstruction. Consequently, the deployment, construction, and maintenance of an all-optical network become significantly easier.

Multiple Ports, Easy Expansion with Various APs

The RG-AM5832-SF-P offers 24 x 1GE/2.5GE/10GE SFP+ downlink ports, enabling an upgrade to Wi-Fi 7 networks without the need to replace the SOE master AP. This allows for seamless integration of 10GE APs and smooth bandwidth upgrades.

The device provides 24 PoE power supply ports that support PoE, PoE+, and PoE++ standards, capable of powering 24 APs over long distances. Each PoE-out port can deliver up to 90 W of PoE power, easily accommodating high-density and high-power APs for concurrent access, ensuring reliable power supply.

No License Required for Identifying and Connecting to SOE Micro APs

The RG-AM5832-SF-P can connect to SOE micro APs and regular APs. No license is required for identifying and connecting to micro APs. This reduces management costs compared to the previous generation of master APs.

WIS Digital Twin Network for Superior Network O&M Efficiency

WIS integrates intelligent O&M functions, including visualized fault locating, along with local, service, and key area network optimization. These capabilities aim to improve operational efficiency and enhance the user experience for wireless networks. Go to WIS Digital Twin Network >

Nerelerde kullanılır?

Ofis, otel, okul ve mağazalarda kesintisiz kablosuz kapsama ve dolaşım (roaming) için tavan veya duvar montajıyla kullanılır.

Teknik özellikler

Değerler üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Boyutlar ve Ağırlık
Boyutlar (G x D x Y)	442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Kutu Boyutları (G x D x Y)	570 mm x 565 mm x 172 mm (22.44 in. x 22.24 in. x 6.77 in.)
Rack size	1 RU
Cihaz Ağırlığı	5.85 kg (12.90 lbs)
Kutulu Ağırlık	7.95 kg (17.53 lbs)
Montaj	Rack-mount

Portlar
Sabit Servis Portları	Uplink:; RG-M5800-2QXS subcard (optional): 2 x 40GE QSFP+ ports; RG-M5800-8VS subcard (optional): 8 x 25GE SFP28 ports, compatibility with 10GE and 1GE modules.; Downlink:; 24 x 10GE SFP+ ports, compatibility with 2.5GE and 1GE modules.; 24 x PoE-out ports, supporting PoE/PoE+/PoE++, with a maximum PoE output power of 90 W per port and a maximum PoE output power of 1,600 W.
Sabit Yönetim Portu	1 x RJ45 10/100/1000Base-T auto-negotiation management port; 1 x RJ45 console port
USB Portu	1 x USB 2.0 port (Type A connector)
Status LED	24 x SFP+ port status LEDs, also indicating the PoE status; RG-M5800-2QXS subcard (optional): 2 x QSFP+ port status LEDs; RG-M5800-8VS subcard (optional): 8 x SFP28 port status LEDs; 1 x system status LED; 2 x power status LEDs; 1 x management (MGMT) port status LED
Buton	1 x Reset button; Press and hold the button for less than 2 seconds to reset the device.; Press and hold the button for more than 5 seconds to restore the device to factory settings.; 1 x LED mode button; Used to switch the status LED to indicate either PoE status or Link/Act status.

Güç Kaynağı ve Tüketim
Input power supply	The RG-AM5832-SF-P supports two hot-swappable 1,000 W power modules, AC input, and DC output for system power supply.; The RG-AM5832-SF-P is delivered with only one AC power module, and you can purchase an additional AC power module.; Rated input voltage range:; AC input: 100 V AC to 130 V AC, 50/60 Hz; AC input: 200 V AC to 240 V AC, 50/60 Hz; HVDC input: 240 V DC; Maximum input current:; 12 A (input voltage: 100 V AC to 130 V AC); 8 A (input voltage: 200 V AC to 240 V AC); 8A (input voltage: 2
External power supply	24 x PoE-out ports, supporting PoE, PoE+, and PoE++; Output voltage: 56 V; Max. output current per port: 1.6 A; Max. PoE output power per port: 90 W; Max. PoE output power: 1,600 W
Maks. Güç Tüketimi	< 200 W (without load); < 2,000 W (full load)

Ortam ve Güvenilirlik
Sıcaklık	Operating temperature: 0°C to 45°C (32°F to 113°F) at an altitude in the range of 0 m to 1,800 m (5,905.51 ft.); Storage temperature: --40°C to +70°C (--40°F to +158°F); At an altitude in the range of 1,800 m to 5,000 m (5,905.51 ft. to 16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F).
Rakım	Operating altitude: --500 m to 5,000 m (--1,640.42 ft. to 16,404.20 ft.); Storage altitude: --500 m to 5,000 m (--1,640.42 ft. to 16,404.20 ft.)
Nem	Operating humidity: 10% RH to 90% RH (non-condensing); Storage humidity: 5% RH to 95% RH (non-condensing)
Yıldırım Koruması	AC power connector: differential mode ±6 kV, common mode ±6 kV; PoE-out port: differential mode ±2 kV, common mode ±6 kV
Fan	Fault alarming and speed adjustment

Yazılım Özellikleri
Applicable software version	RGOS12.6(3)B0401 or later

WLAN
Max. number of associated STAs	1,536
Max. number of BSSIDs	64
STA management	SSID hiding; Band steering (When used with an AC, the master AP enables STAs to preferentially access the 5 GHz band.)

Güvenlik
Authentication and encryption	Remote Authentication Dial-In User Service (RADIUS); PSK, Web-based authentication, and 802.1X authentication; Data encryption: WPA (TKIP), WPA-PSK, WPA2 (AES), WEP (64/128-bit); QR code-based guest authentication, SMS-based authentication, and MAB authentication (The master AP needs to work with an RG-WS series AC.)
Data frame filtering	Allowlist, static blocklist, and dynamic blocklist
WIDS	Wireless Intrusion Detection System (WIDS); User isolation; Rogue AP detection and containment
ACL	Dynamic ACL assignment based on 802.1X authentication (The master AP needs to work with an AC.)
CPU Protect Policy (CPP)	Destekleniyor
NFPP	Destekleniyor

Routing and Switching
MAC	MAC address auto-learning and MAC address entry aging; Static and dynamic MAC address entries; Source MAC address filtering; MAC address limit learned on an interface
Ethernet	Jumbo frame length: 9,216; IEEE 802.1p and IEEE 802.1Q; Optical module information displaying, fault alarming, and diagnostic parameter measurement (QSFP+/SFP28/SFP+/SFP)
VLAN	Port-based VLAN; Max. number of SVIs: 1,000; Number of VLANs that can be created: 4,094; Available VLAN ID range: 1 to 4,094
ARP	ARP entry aging, gratuitous ARP learning, and ARP proxy; ARP entries: 24,000; ARP check
IPv4 services	Static IPv4 address and DHCP-assigned IPv4 address; DHCP server and DHCP client; DHCP snooping; DNS client and DNS proxy; NTP server, NTP client, and SNTP client
IPv6 services	Manually configured and automatically created IPv6 addresses; IPv6 CAPWAP tunnel; IPv6 neighbor discovery (ND), IPv6 ND proxy, ICMPv6, and IPv6 ping; DNSv6 client; NTPv6 server and NTPv6 client
IP Yönlendirme	IPv4/IPv6 static routing; Static IPv4 routing table: 24,000; Static IPv6 routing table: 14,000; Static blackhole route
Multicast	Destekleniyor

Network Management and Monitoring
Ağ Yönetimi	SNMP v1/v2c/v3; Fault detection and alarming
User access management	Console, Telnet, SSH, TFTP, and FTP

Uyumluluk
Uyumluluk	EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, EN 300 386, IEC 62368-1, and EN 62368-1

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Product DatasheetPDF
