Aruba JL678A CX6100 24G 4SFP+ Yönetilebilir Switch
JL678AAruba JL678A, 48 portlu gigabit bir yönetilebilir switch'tir. PoE portları IP kamera, access point ve IP telefon gibi cihazları tek ağ kablosu üzerinden besler. 4 adet SFP portu ile fiber uplink bağlantısı kurulabilir. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.
- Port hızı
- Gigabit
- PoE
- PoE
- Port sayısı
- 48 port
Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.
- It simplifies IT operations with next-gen Layer 2 switch series that provides entry-level, reliable, and convenient wired access connectivity
- The CX 6100 series provides right size with 12, 24, and 48-port 1U models with convenient built-in 1/10GbE uplinks and up to 740W of Class 4 PoE
- It has compact and fan-less 12-port PoE model for space-constrained deployments
- The CX 6100 provides flexibility to manage and simplify configurations
- It offers scalability with a 6-member switch virtual switching framework (VSF) stacking
Teknik özellikler
Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.
Genel 1 satır
| Ürün Adı (Üretici) | HPE Networking CX6100 24G 4SFP+ Switch |
|---|
Teknik Özellikler 11 satır
| Model Farkı | Non-PoE |
|---|---|
| Güç Tüketimi | Max. Power (w/o PoE): 33W |
| Portlar | 24 x 10/100/1000BASE-T ports 4 x 1G/10G SFP ports 1 x USB-C console port 1 x USB Type-A host port |
| Gecikme | 1 Gbps: 1.5 Sec , 10 Gbps: 1.8 Sec |
| Anahtarlama Kapasitesi | 128 Gbps |
| Veri Hızı | 95.2 Mpps |
| Bellek ve İşlemci | Dual Core ARM Cortex A9 @ 1016 Mhz 4 GB DDR3, maximum, depending on model 16 GB eMMC |
| PoE Kapasitesi | Non-PoE model |
| Çalışma Sıcaklığı | Maximum of 32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km) derate by 1°C for every 1000 ft (305m) from 5000 ft (1.5 km) to 10000 ft (3.0 km) |
| Yönetim Özellikleri | Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software |
| Garanti | Limited lifetime warranty. |
Seri Özellikleri 3 satır
| Giriş Gerilimi | 100–127 VAC / 200–240 VAC |
|---|---|
| Güç Kaynağı | Fixed power supply |
| Fanlar | Fixed fans |
Genel bakış
Aruba JL678A kullanım alanları ve özellikleri.
The HPE Aruba Networking CX 6100 Switch Series is a modern family of entrylevel access switches ideal for branch offices, mid-market enterprises, and SMB networks. Designed for reliable, simple, and secure access, this switch family provides a convenient wired access solution for enterprise networks supporting Internet of Things (IoT), mobile, and cloud applications.
Prepare your network for future demands with a powerful ASIC and the programmable HPE Aruba Networking CX Switch Operating System to deliver a more consistent, more efficient operator experience. This Layer 2 switch series has convenient built-in high speed uplinks with up to 740W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12-port model is ideal for use in quiet workspaces. With robust quality of service (QoS), support for static routing, and IPv6, these
switches also simplify ownership with no switch software licensing requirements.
The HPE Aruba Networking CX 6100 Switch Series offers gigabit connectivity with high-speed uplinks and optional PoE to provide entry-level, reliable, and convenient wired access connectivity for enterprise branch office and SMB networks.
- It simplifies IT operations with next-gen Layer 2 switch series that provides entry-level, reliable, and convenient wired access connectivity
- The CX 6100 series provides right size with 12, 24, and 48-port 1U models with convenient built-in 1/10GbE uplinks and up to 740W of Class 4 PoE
- It has compact and fan-less 12-port PoE model for space-constrained deployments
- The CX 6100 provides flexibility to manage and simplify configurations
- It offers scalability with a 6-member switch virtual switching framework (VSF) stacking
Nerelerde kullanılır?
Kurumsal ağlarda VLAN ile kamera, misafir ve ofis trafiğini ayırmak, uplink ve omurga bağlantılarını yönetmek için kullanılır.
Dokümanlar
Veri sayfası ve kullanım kılavuzları.
Sık sorulanlar
JL678A hakkında kısa yanıtlar.
JL678A IP kamera beslemek için uygun mu?
JL678A kaç portlu?
JL678A fiyatı ne kadar?
Hızlı teklif
Formu doldurun, JL678A için fiyat ve teslim süresini iletelim.
