Aruba
Aruba R9W89A CX8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 BF 3xFan 2AC PSU Veri Merkezi Switch
Aruba R9W89A CX8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 BF 3xFan 2AC PSU Veri Merkezi Switch — görsel 2
1 / 2
Yönetilebilir Switch CX 8100

Aruba R9W89A CX8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 BF 3xFan 2AC PSU Veri Merkezi Switch

ModelR9W89A

Aruba R9W89A bir yönetilebilir switch'tir. Öne çıkan özellikleri: high performance 1.76 tbps of bidirectional switching and 1,309 mpps of forwarding designed for aggregation in the campus or top-ofrack (tor) in data center environments, four different base models, each sold in bundles that support two airflow modes (front-to-back, and back-tofront) with advanced layer 2/3 feature set that includes bgp, ospf, vrf, vxlan, evpn, ipv6, high availability with industry-leading hpe aruba networking virtual switching extension (vsx) redundancy and redundant power supplies and fans, hpe aruba networkin...

Port hızı
10G uplink
PoE
PoE yok
Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara
Distribütör garantili
81 ile sevkiyat
Teknik destek
  • High performance 1.76 Tbps of bidirectional switching and 1,309 Mpps of forwarding designed for aggregation in the campus or top-ofrack (ToR) in data center environments
  • Four different base models, each sold in bundles that support two airflow modes (front-to-back, and back-tofront) with advanced Layer 2/3 feature set that includes BGP, OSPF, VRF, VXLAN, EVPN, IPv6
  • High availability with industry-leading HPE Aruba Networking Virtual Switching Extension (VSX) redundancy and redundant power supplies and fans
  • HPE Aruba Networking CX Switch Operating System (AOS-CX) automation and programmability using built-in REST APIs and Python scripts
  • Intelligent monitoring and visibility delivered by the HPE Aruba Networking CX Networks Analytics Engine (NAE)

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Genel 1 satır
Ürün Adı (Üretici)HPE Networking CX8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 BF 3xFan 2AC PSU Switch Bundle
Teknik Özellikler 11 satır
Model FarkıCX 8100 24 x 10G 4 x 10G 4 x 40/100G back-to-front bundle
Güç TüketimiMaximum: 400W Idle: 120W
Isı Yayılımı1364 BTU/hr
Giriş Gerilimi100–127V 7.1A for 100–127 VAC 200–240V 3.4A for 200–240 VAC
Portlar24 ports of 100M/1/2.5/5/10GbE 4 ports of 1/10GbE (SFP/SFP+) 4 ports of 40/100GbE (QSFP+/QSFP28)
Anahtarlama Kapasitesi1.36 Tbps
Bellek ve İşlemciCPU: Quad Core Arm® Cortex™ A72 @ 1.8 GHz Memory and flash: 16 GB RAM, 32 GB Flash/storage Packet buffer: 32 MB
Güç KaynağıBundles include the 2 power supplies (2 x JL712A in R9W87A, R9W89A, R9W91A, and R9W93A)
Çalışma Sıcaklığı32°F to 104°F (0°C to 40°C) up to 5000 ft depending on the model
GarantiLimited lifetime warranty.
Fanlar3 field-replaceable and hot-swappable fans
Seri Özellikleri 2 satır
Veri Hızı1,309 Mpps
Yönetim ÖzellikleriRJ-45 serial and USB-C console RJ-45 Ethernet port USB Type-A

Genel bakış

Aruba R9W89A kullanım alanları ve özellikleri.

The HPE Aruba Networking CX 8100 Switch Series serves the needs of modern campus core and aggregation as well as dynamic top-of-rack (ToR) data center environments, offering a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT.

The CX 8100 switches are based on HPE Aruba Networking CX Switch Operating System (AOS-CX) that automates and simplifies critical network tasks, offers programmability with REST APIs and Python scripts, delivers enhanced fault tolerance and zero-service disruption during planned or unplanned control-plane events. Real-time, network-wide visibility and analytics are available in every switch.

The series includes industry-leading line rate ports with 1/10GbE (SFP/SFP+) and 40/100GbE (QSFP+/QSFP28) connectivity in a compact 1U form factor. 4 x 10 Gbps and 4 x 25 Gbps break out from 40/100G. These switches are great for customers needing 1/10GbE with mix of fiber and copper ports.

HPE Aruba Networking CX 8100 Switch Series features HPE Aruba Networking CX Switch Operating System (AOS- CX) which simplifies the complexity of managing data center networks with automation options to match your IT organization’s operating model.

  • High performance 1.76 Tbps of bidirectional switching and 1,309 Mpps of forwarding designed for aggregation in the campus or top-ofrack (ToR) in data center environments
  • Four different base models, each sold in bundles that support two airflow modes (front-to-back, and back-tofront) with advanced Layer 2/3 feature set that includes BGP, OSPF, VRF, VXLAN, EVPN, IPv6
  • High availability with industry-leading HPE Aruba Networking Virtual Switching Extension (VSX) redundancy and redundant power supplies and fans
  • HPE Aruba Networking CX Switch Operating System (AOS-CX) automation and programmability using built-in REST APIs and Python scripts
  • Intelligent monitoring and visibility delivered by the HPE Aruba Networking CX Networks Analytics Engine (NAE)

Nerelerde kullanılır?

Kurumsal ağlarda VLAN ile kamera, misafir ve ofis trafiğini ayırmak, uplink ve omurga bağlantılarını yönetmek için kullanılır.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet - HPE Aruba Networking CX 8100 Switch SeriesPDF · R9W89A
