ORing
ORing IGAP-W612H+ Dış Ortam WIFI4 Kablosuz AP ve 1GE, IP67, PoE P.D Endüstriyel Access Point
Kablosuz Access Point IGAP-W612 Serisi

ORing IGAP-W612H+ Dış Ortam WIFI4 Kablosuz AP ve 1GE, IP67, PoE P.D Endüstriyel Access Point

ModelIGAP-W612H+

ORing IGAP-W612H+ endüstriyel access point: Dual Band in IEEE 802.11 a/b/g/n and b/g/n WLAN interface selectable and support up to 300Mbps link speed, Highly Security Capability: WEP/WPA/WPA-PSK(TKIP,AES)/ WPA2/WPA2-PSK(TKIP,AES)/802.1X Authentication supported, High data throughput with HT40 2x2 MIMO.

Port sayısı
45 port
Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara
Distribütör garantili
81 ile sevkiyat
Teknik destek
  • Dual Band in IEEE 802.11 a/b/g/n and b/g/n WLAN interface selectable and support up to 300Mbps link speed
  • Highly Security Capability: WEP/WPA/WPA-PSK(TKIP,AES)/ WPA2/WPA2-PSK(TKIP,AES)/802.1X Authentication supported
  • High data throughput with HT40 2x2 MIMO
  • High transmission power(27 dBm Max.)
  • Support X-Roaming < 100 ms
  • Support AP/Client/Repeater Mode
  • Support MAC Filtering
  • Wireless connecting status monitoring

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Fiziksel Portlar 1 satır
10/100/1000Base-T(X) ports in RJ45__1(with PoE)__
LED Göstergeler 4 satır
WIFI(WLAN) Indicator3 x LED,; Green for 1 x 2.4G, 1 x 5G; 1x WLAN Strength:; Solid > 75%; Blink 2 sec/time => 74%~50%; Blink 1 sec/time => 49%~25%; Blink 500 msec/time => ≤25%
Güç Göstergesi1 x LED,; Green On: Power(PoE) is on and functioning Normally.
System Indicator (Status)Green On: System ready, Blinking: System booting
10/100/1000Base-T(X) RJ45 port indicator1 x LED,; Green On: Port Link / Act, Blinking: data transmission
Güç 2 satır
Güç Tüketimi (Tipik)7 W
Güç Girişi48VDC from P.o.E
Kablosuz (WLAN) Arayüz 7 satır
Çalışma ModuAP/Client/Repeater
Anten Konnektörü2 x External N-type antenna connector
ModülasyonIEEE802.11a: OFDM; IEEE802.11b: CCK/DQPSK/DBPSK; IEEE802.11g: OFDM; IEEE802.11n: BPSK, QPSK, 16-QAM, 64-QAM
Frekans BandıAmerica/FCC: 2.412~2.462 GHz (11 channels); 5.180~5.240 GHz & 5.745~5.825 GHz ( 9 channels ); Europe CE/ETSI: 2.412~2.472 GHz (13 channels); 5.180~5.240 GHz ( 4 channels )
İletim Hızı802.11b: 11, 5.5, 2, 1 Mbps;; 802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps; 802.11n: up to 300Mbps
Yayın Gücü802.11a: 23dBm ± 1.5dBm@6Mbps, 21dBm ± 1.5dBm@54Mbps; 802.11b: 23dBm ± 1.5dBm@1Mbps, 23dBm ± 1.5dBm@11Mbps; 802.11g: 23dBm ± 1.5dBm@6Mbps, 21dBm ± 1.5dBm@54Mbps; 802.11gn HT20: 20dBm ± 1.5dBm@MCS7, 802.11gn HT40: 20dBm ± 1.5dBm @MCS7; 802.11an HT20: 20dBm ± 1.5dBm@MCS7, 802.11an HT40: 20dBm ± 1.5dBm @MCS7
Şifreleme GüvenliğiWEP: (64-bit,128-bit key supported); WPA/WPA2 :802.11i(WEP and AES encryption); WPAPSK (256-bit key pre-shared key supported); 802.1X Authentication supported; TKIP encryption
Protocol Support 1 satır
ProtokolARP, BOOTP, DHCP, DNS, HTTPs, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, STP (IEEE 802.1D)
Fiziksel Özellikler 3 satır
KasaIP-67
Dimensions (mm)220.42(W)x 127.42(D)x 75(H)
Ağırlık (g)1148
Ortam Koşulları 3 satır
Depolama Sıcaklığı-30 to 85°C (-22 to 185°F)
Çalışma Sıcaklığı-10 to 70°C (14 to 158°F)
Çalışma Nemi100% Non-condensing
Garanti 1 satır
Garanti5 years
Sertifikalar ve Onaylar 8 satır
EMCCE EMC (EN 55024, EN 55032), FCC Part 15B
EMIEN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15B class A
EMSEN 55024 (IEC/EN 61000-4-2 (ESD), IEC/EN 61000-4-3 (RS), IEC/EN 61000-4-4 (EFT), IEC/EN 61000-4-5 (Surge), IEC/EN 61000-4-6 (CS), IEC/EN61000-4-8(PFMF), IEC/EN 61000-4-11(DIP))
Darbe DayanımıIEC60068-2-27
Serbest DüşmeIEC60068-2-31
TitreşimIEC60068-2-6
Güvenlik StandardıEN60950-1
MTBF250109 hours

Genel bakış

ORing IGAP-W612H+ kullanım alanları ve özellikleri.

ORing IGAP-W612H+ – Outdoor Industrial WIFI4 Wireless AP with 1GE, IP67, PoE P.D. Bu ürün ORing Industrial Networking'in Endüstriyel Access Point ailesinde yer alır.

Öne Çıkan Teknik Özellikler

  • Güç Tüketimi (Tipik): 7 W
  • Frekans Bandı: America/FCC: 2.412~2.462 GHz (11 channels); 5.180~5.240 GHz & 5.745~5.825 GHz ( 9 channels ); Europe CE/ETSI: 2.412~2.472 GHz (13 channels); 5.180~5.240 GHz ( 4 channels )
  • İletim Hızı: 802.11b: 11, 5.5, 2, 1 Mbps;; 802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps; 802.11n: up to 300Mbps
  • Kasa: IP-67
  • Çalışma Sıcaklığı: -10 to 70°C (14 to 158°F)
  • Garanti: 5 years
  • MTBF: 250109 hours

Temel Özellikler (Features)

  • Dual Band in IEEE 802.11 a/b/g/n and b/g/n WLAN interface selectable and support up to 300Mbps link speed
  • Highly Security Capability: WEP/WPA/WPA-PSK(TKIP,AES)/ WPA2/WPA2-PSK(TKIP,AES)/802.1X Authentication supported
  • High data throughput with HT40 2x2 MIMO
  • High transmission power(27 dBm Max.)
  • Support X-Roaming < 100 ms
  • Support AP/Client/Repeater Mode
  • Support MAC Filtering
  • Wireless connecting status monitoring
  • HTTPs protocol supported for secured management
  • Event Warning by Syslog, Email, SNMP Trap
  • Rigid IP-67 housing design
  • Pole-mount enabled

Genel Bakış (Description)

IGAP-W612H+ is a reliable IP-67 outdoor IEEE 802.11 a/b/g/n WLAN Access Point with 1 PoE P.D. Ethernet port. It can be configured to operate in AP/Client/Repeater mode. It is specifically designed for the toughest industrial environments. In combination with its IP-67 design and the superb management functionality, IGAP-W612H+ provides a waterproof, dust-tight connection. In addition, IGAP-W612H+ provides a high power output of 27 dBm and high throughput up to 180Mbps to satisfy far distance connection. IGAP-W612H+ provides two N-type connectors, which can install any N-type antennas to extend communication distance. You are able to configure IGAP-W612H+ by WEB interface via LAN port or WLAN interface. In addition, IGAP-W612H+ also provides P.D. feature which is fully compliant with the IEEE802.3at PoE P.D. specification to save the layout cost of the power line. IGAP-W612H+ can be easily adopted in almost all kinds of applications and provides the most rugged solutions for managing your network in outdoor. Therefore, IGAP-W612H+ is one of the best outdoor communication solutions for wireless applications

Nerelerde kullanılır?

Ofis, otel, okul ve mağazalarda kesintisiz kablosuz kapsama ve dolaşım (roaming) için tavan veya duvar montajıyla kullanılır.

Tüm özellikler

  • Dual Band in IEEE 802.11 a/b/g/n and b/g/n WLAN interface selectable and support up to 300Mbps link speed
  • Highly Security Capability: WEP/WPA/WPA-PSK(TKIP,AES)/ WPA2/WPA2-PSK(TKIP,AES)/802.1X Authentication supported
  • High data throughput with HT40 2x2 MIMO
  • High transmission power(27 dBm Max.)
  • Support X-Roaming < 100 ms
  • Support AP/Client/Repeater Mode
  • Support MAC Filtering
  • Wireless connecting status monitoring
  • HTTPs protocol supported for secured management
  • Event Warning by Syslog, Email, SNMP Trap
  • Rigid IP-67 housing design
  • Pole-mount enabled

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet (EN)PDF · IGAP-W612H+ Hızlı Kurulum Kılavuzu (EN)PDF · IGAP-W612H+ Kullanım Kılavuzu (EN)PDF · IGAP-W612H+
