ORing

Endüstriyel Switch IGS-9168 Serisi

ORing IGS-9168GP-PN PROFINET CC-B Ethernet Switch ve 16GE ve 8G SFP Endüstriyel Yönetilebilir Switch

Q: IGS-9168GP-PN kaç portlu?

IGS-9168GP-PN 45 porta sahiptir.

Q: IGS-9168GP-PN fiyatı ne kadar?

IGS-9168GP-PN için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.

ModelIGS-9168GP-PN

ORing IGS-9168GP-PN, 45 portlu gigabit bir endüstriyel switch'tir. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.

Port hızı: Gigabit
PoE: PoE yok
Port sayısı: 45 port

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

PROFINET CC-B v2.40 certified and GSD file provided
Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) for Ethernet Redundancy
Open-Ring support the other vendor's ring technology in open architecture
O-Chain allow multiple redundant network rings
Support PROFINET MRP client (MRC)
Support IEEE 1588v2 clock Synchronization
Support IPV6 new internet protocol version
Support Modbus TCP and Ethernet/IP protocol

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Fiziksel Portlar 2 satır

10/100Base-T(X) ports in RJ45	16
100/1000Base-X with SFP port	8

LED Göstergeler 6 satır

Power Indicator (Power)	Green : Power LED x 3
Ring Master Indicator (R.M.)	Green : Indicates that the system is operating in O-Ring Master mode
O-Ring Indicator (Ring)	Green : Indicates that the system operating in O-Ring mode; Green Blinking : Indicates that the Ring is broken.
Fault Indicator (Fault)	Amber : Indicate unexpected event occurred
10/100/1000Base-T(X) RJ45 port indicator	Green for Port LINK/ACT indicator; Dual color LED for speed indicator: Green for 1000Mbps / Amber for 100Mbps / off-light for 10Mbps
100/1000Base-X SFP Port Indicator	Green for port Link/Act.

Güç 4 satır

Güç Tüketimi (Tipik)	20 Watts (Full loading)
Yedekli Güç Girişi	Dual DC inputs. 12~48VDC on 6-pin terminal block
Aşırı Akım Koruması	Present
Ters Polarite Koruması	Present

Fiziksel Özellikler 3 satır

Kasa	IP-30
Dimensions (mm)	96.4 (W) x 105.5 (D) x 154 (H)mm
Ağırlık (g)	1250 g

Teknoloji 10 satır

Ethernet Standartları	IEEE 802.3 for 10Base-T; IEEE 802.3u for 100Base-TX and 100Base-FX; IEEE 802.3ab for 1000Base-T; IEEE 802.3z for 1000Base-X; IEEE 802.3x for Flow control; IEEE 802.3ad for LACP (Link Aggregation Control Protocol ); IEEE 802.1p for COS (Class of Service); IEEE 802.1Q for VLAN Tagging; IEEE 802.1D for STP (Spanning Tree Protocol); IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol); IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol); IEEE 802.1x for Authentication; IEEE 802.1AB for LLDP (Link
PROFINET conformance class	Conformance-class B
MAC Adres Tablosu	8k
Priority Queues	8
Anahtarlama Yöntemi	Store-and-Forward
Switch Özellikleri	Switching latency: 7 us; Switching bandwidth: 48Gbps; Throughput (packet per second) : 35.71Mpps@64Bytes packet; Max. Number of Available VLANs: 4096; VLAN ID Range : VID 0 to 4095; IGMP multicast groups: 256 for each VLAN; Port rate limiting: User Define
Jumbo Frame	Up to 9.6K Bytes
Security Features	Device Binding security feature; Enable/disable ports, MAC based port security; Port based network access control (802.1x); VLAN (802.1Q ) to segregate and secure network traffic; Radius centralized password management; SNMPv3 encrypted authentication and access security; Https / SSH enhance network security
Software Features	STP/RSTP/MSTP (IEEE 802.1D/w/s); Redundant Ring (O-Ring) with recovery time less than 20ms over 250 units; TOS/Diffserv supported; Quality of Service (802.1p) for real-time traffic; VLAN (802.1Q) with VLAN tagging; IGMP Snooping; IP-based bandwidth management; Application-based QoS management; DOS/DDOS auto prevention; Port configuration, status, statistics, monitoring, security; DHCP Server/Client/Relay; SMTP Client; Modbus TCP; NTP server
Network Redundancy	O-Ring; Open-Ring; O-Chain; MRP; MSTP (RSTP/STP compatible)

Arıza Kontağı 1 satır

Röle Çıkışı	Relay output to carry capacity of 1A at 24VDC

Reset Function 1 satır

Reset Butonu	5 sec: Factory default

Ortam Koşulları 3 satır

Depolama Sıcaklığı	-40 to 85oC (-40 to 185oF)
Çalışma Sıcaklığı	-40 to 75oC (-40 to 167oF )
Çalışma Nemi	5% to 95% Non-condensing

Garanti 1 satır

Garanti	5 years

Sertifikalar ve Onaylar 7 satır

EMC	CE EMC (EN 55035, EN 55032), FCC Part 15 B
EMI	EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A
EMS	IEC/EN 61000-4-2 (ESD); IEC/EN 61000-4-3 (RS); IEC/EN 61000-4-4 (EFT); IEC/EN 61000-4-5 (Surge); IEC/EN 61000-4-6 (CS); IEC/EN 61000-4-8(PFMF)
Darbe Dayanımı	IEC60068-2-27
Serbest Düşme	IEC60068-2-31
Titreşim	IEC60068-2-6
Güvenlik Standardı	UL61010-1

Genel bakış

ORing IGS-9168GP-PN kullanım alanları ve özellikleri.

ORing IGS-9168GP-PN – PROFINET CC-B Ethernet Switch with 16GE and 8G SFP. Bu ürün ORing Industrial Networking'in Endüstriyel Yönetilebilir Switch ailesinde yer alır.

Öne Çıkan Teknik Özellikler

Güç Tüketimi (Tipik): 20 Watts (Full loading)
Yedekli Güç Girişi: Dual DC inputs. 12~48VDC on 6-pin terminal block
Kasa: IP-30
MAC Adres Tablosu: 8k
Jumbo Frame: Up to 9.6K Bytes
Çalışma Sıcaklığı: -40 to 75oC (-40 to 167oF )
Garanti: 5 years

Temel Özellikler (Features)

PROFINET CC-B v2.40 certified and GSD file provided
Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) for Ethernet Redundancy
Open-Ring support the other vendor's ring technology in open architecture
O-Chain allow multiple redundant network rings
Support PROFINET MRP client (MRC)
Support IEEE 1588v2 clock Synchronization
Support IPV6 new internet protocol version
Support Modbus TCP and Ethernet/IP protocol
Provided HTTPS/SSH protocol to enhance network security
Support IEEE 802.3az Energy-Efficient Ethernet technology
Support SMTP client
Support IP-based bandwidth management
Support application-based QoS management
Support Device Binding
Support backup unit device DBU-01 to quickly configuration backup/restore

Genel Bakış (Description)

IGS-9168GP-PN is a managed redundant ring Ethernet switch with 16x 10/100/1000Base-T(X) ports and 8x 100/1000Base-X SFP ports. It fully supports Ethernet redundancy protocols including O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible), ensuring fast recovery technology to protect mission-critical applications from network interruptions or temporary malfunctions. The switch operates over a wide temperature range from -40°C to 75°C. IGS-9168GP-PN can be centrally managed conveniently via Open-Vision, excluding the Web-based interface, Telnet, and console (CLI) configuration. Being PROFINET CC-B certified, it guarantees compatibility and interoperability in industrial automation applications, ensuring seamless integration and enhanced network performance. Therefore, this switch is one of the most reliable choices for highly managed fiber Ethernet applications, particularly in industrial automation environments benefiting from PROFINET CC-B certification.

Nerelerde kullanılır?

Fabrika sahası, trafik dolapları ve açık alan panolarında geniş sıcaklık aralığında kesintisiz çalışacak şekilde tasarlanmıştır.

Tüm özellikler

PROFINET CC-B v2.40 certified and GSD file provided
Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) for Ethernet Redundancy
Open-Ring support the other vendor's ring technology in open architecture
O-Chain allow multiple redundant network rings
Support PROFINET MRP client (MRC)
Support IEEE 1588v2 clock Synchronization
Support IPV6 new internet protocol version
Support Modbus TCP and Ethernet/IP protocol
Provided HTTPS/SSH protocol to enhance network security
Support IEEE 802.3az Energy-Efficient Ethernet technology
Support SMTP client
Support IP-based bandwidth management
Support application-based QoS management
Support Device Binding
Support backup unit device DBU-01 to quickly configuration backup/restore

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet (EN)PDF · IGS-9168GP-PN
