ORing IGS-9084GP 8GE + 4G SFP Endüstriyel Yönetilebilir Switch
Endüstriyel Switch IGS-9084 Serisi

ORing IGS-9084GP 8GE + 4G SFP Endüstriyel Yönetilebilir Switch

ModelIGS-9084GP

ORing IGS-9084GP gigabit bir endüstriyel switch'tir. VLAN, QoS ve port izleme gibi yönetim özellikleri sunar.

Port hızı
Gigabit
PoE
PoE yok
Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara
Distribütör garantili
81 ile sevkiyat
Teknik destek
  • Support O-Ring, O-Chain, RSTP/MSTP(STP compatible), IEC 62439-2 MRP , G.8032 ERPS for Ethernet Redundancy
  • Support IPV6 new internet protocol version
  • Support Modbus TCP and Ethernet/IP protocol
  • Support IEEE 802.3az Energy-Efficient Ethernet technology
  • Provided HTTPS/SSH protocol to enhance network security
  • Support SMTP client and NTP server protocol
  • Support IP-based bandwidth management
  • Support application-based QoS management

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Fiziksel Portlar 2 satır
10/100/1000Base-T(X) ports in RJ458
1000/2500Base-X with SFP port4
Teknoloji 8 satır
Ethernet StandartlarıIEEE 802.3 for 10Base-T; IEEE 802.3u for 100Base-TX and 100Base-FX; IEEE 802.3ab for 1000Base-T; IEEE 802.3z for 1000Base-X; IEEE 802.3x for Flow control; IEEE 802.3ad for LACP (Link Aggregation Control Protocol); IEEE 802.1p for COS (Class of Service); IEEE 802.1Q for VLAN Tagging; IEEE 802.1D for STP (Spanning Tree Protocol); IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol); IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol); IEEE 802.1x for Authentication; IEEE 802.1AB for LLDP (Link L
MAC Adres Tablosu8K
Anahtarlama YöntemiStore-and-Forward
Switch ÖzellikleriSwitching latency: 7 us; Switching bandwidth: 24Gbps; Max. Number of Available VLANs: 4096; IGMP multicast groups: 128 for each VLAN; Port rate limiting: User Define
Jumbo FrameUp to 9.6K Bytes
Security FeaturesDevice Binding security feature; Enable/disable ports, MAC based port security; Port based network access control (802.1x); VLAN (802.1Q ) to segregate and secure network traffic; Radius centralized password management; SNMPv3 encrypted authentication and access security; Https / SSH enhance network security
Software FeaturesMSTP (RSTP/STP compatible); Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units; TOS/Diffserv supported; Quality of Service (802.1p) for real-time traffic; VLAN (802.1Q) with VLAN tagging; IGMP Snooping; IP-based bandwidth management; Application-based QoS management; DOS/DDOS auto prevention; Port configuration, status, statistics, monitoring, security; DHCP Server/Client/Relay; SMTP Client; Modbus TCP; NTP server
Network RedundancyO-Ring; O-Chain; MRP*NOTE; MSTP (RSTP/STP compatible)
Ortam Koşulları 3 satır
Depolama Sıcaklığı-40 to 85℃ (-40 to 185℉)
Çalışma Sıcaklığı-40 to 75℃ (-40 to 167℉)
Çalışma Nemi5% to 95% Non-condensing
Garanti 1 satır
Garanti5-year
Sertifikalar ve Onaylar 6 satır
EMCCE EMC (EN 55035, EN 55032), FCC Part 15 B
EMIEN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A
EMSIEC/EN 61000-4-2 (ESD); IEC/EN 61000-4-3 (RS); IEC/EN 61000-4-4 (EFT); IEC/EN 61000-4-5 (Surge); IEC/EN 61000-4-6 (CS); IEC/EN 61000-4-8(PFMF)
Darbe DayanımıIEC60068-2-27
Serbest DüşmeIEC60068-2-31
TitreşimIEC60068-2-6

Genel bakış

ORing IGS-9084GP kullanım alanları ve özellikleri.

ORing IGS-9084GP – 8GE + 4G SFP Managed Ethernet Switch. Bu ürün ORing Industrial Networking'in Endüstriyel Yönetilebilir Switch ailesinde yer alır.

Öne Çıkan Teknik Özellikler

  • MAC Adres Tablosu: 8K
  • Jumbo Frame: Up to 9.6K Bytes
  • Çalışma Sıcaklığı: -40 to 75℃ (-40 to 167℉)
  • Garanti: 5-year

Temel Özellikler (Features)

  • Support O-Ring, O-Chain, RSTP/MSTP(STP compatible), IEC 62439-2 MRP , G.8032 ERPS for Ethernet Redundancy
  • Support IPV6 new internet protocol version
  • Support Modbus TCP and Ethernet/IP protocol
  • Support IEEE 802.3az Energy-Efficient Ethernet technology
  • Provided HTTPS/SSH protocol to enhance network security
  • Support SMTP client and NTP server protocol
  • Support IP-based bandwidth management
  • Support application-based QoS management
  • Support Device Binding security function
  • Support DoS/DDoS auto prevention
  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
  • Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management
  • Support ACL, TACACS+ and 802.1x User Authentication for security
  • Support 9.6K Bytes Jumbo Frame
  • Syslog/SNMP Trap notification for warning of unexpected event

Genel Bakış (Description)

IGS-9084GP is a managed Ethernet switch with 8x 10/100/1000Base-T(X) ports and 4x 100/1000Base-X SFP ports. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. And support wide operating temperature from -40 o C to 75 o C. IGS-9084GP can also be managed centralized and convenient by Open-Vision, except the Web-based interface, Telnet and console (CLI) configuration. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber Ethernet application.

Nerelerde kullanılır?

Fabrika sahası, trafik dolapları ve açık alan panolarında geniş sıcaklık aralığında kesintisiz çalışacak şekilde tasarlanmıştır.

Tüm özellikler

  • Support O-Ring, O-Chain, RSTP/MSTP(STP compatible), IEC 62439-2 MRP , G.8032 ERPS for Ethernet Redundancy
  • Support IPV6 new internet protocol version
  • Support Modbus TCP and Ethernet/IP protocol
  • Support IEEE 802.3az Energy-Efficient Ethernet technology
  • Provided HTTPS/SSH protocol to enhance network security
  • Support SMTP client and NTP server protocol
  • Support IP-based bandwidth management
  • Support application-based QoS management
  • Support Device Binding security function
  • Support DoS/DDoS auto prevention
  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
  • Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management
  • Support ACL, TACACS+ and 802.1x User Authentication for security
  • Support 9.6K Bytes Jumbo Frame
  • Syslog/SNMP Trap notification for warning of unexpected event
  • Support DBU-01 backup unit device to quickly backup/restore configuration
  • Web-based ,SNMP v1/v2c/v3, Telnet, Console (CLI), and Windows utility ( Open-Vision ) configuration
  • Robust EMS design, provide 8K ESD and 4KV Surge protection
  • Rigid IP-30 housing design
  • DIN-Rail and wall mounting enabled

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet (EN)PDF · IGS-9084GP Hızlı Kurulum Kılavuzu (EN)PDF · IGS-9084GP Kullanım Kılavuzu (EN)PDF · IGS-9084GP
