Cisco C9120AXI Wi-Fi 6 İç Ortam Access Point

ModelC9120AXI

Cisco C9120AXI access point: Wi-Fi 6 standardı, Kullanım: İç Ortam, Wi-Fi 6 (802.11ax), Cisco RF ASIC, Uplink/downlink OFDMA.

Kablosuz standart: Wi-Fi 6

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

Wi-Fi 6 standardı
Kullanım: İç Ortam
Wi-Fi 6 (802.11ax)
Cisco RF ASIC
Uplink/downlink OFDMA
MU‑MIMO technology
BSS coloring
Target wake time

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Sipariş Bilgileri 2 satır

Sipariş Kodları (PID)	C9120AXI-x (x = regülasyon bölgesi), C9120AXI-EWC-x (x = regülasyon bölgesi)
Planlanan Satış Sonu (End-of-Sale) Tarihi	31.12.2026

Teknik Özellikler 15 satır

802.11n Özellikleri	4x4 MIMO with four spatial streams; Maximal Ratio Combining (MRC); 802.11n and 802.11a/g beamforming; 20- and 40-MHz channels; PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz); Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive); 802.11 Dynamic Frequency Selection (DFS); Cyclic Shift Diversity (CSD) support
802.11ac (Wi-Fi 5)	4x4 downlink MU-MIMO with four spatial streams; MRC; 802.11ac beamforming; 20-, 40-, 80-, and 160-MHz channels; PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz); Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive); 802.11 DFS; CSD support
802.11ax (Wi-Fi 6/6E)	4x4 downlink MU-MIMO with four spatial streams; Uplink/downlink OFDMA; TWT; BSS coloring; MRC; 802.11ax beamforming; 20-, 40-, 80-, and 160-MHz channels; PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz); Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive); 802.11 DFS; CSD support
Dahili Anten	Flexible radio (either on 2.4 GHz or on 5 GHz); 2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth; 5 GHz, peak gain 5 dBi, internal antenna, omnidirectional in azimuth; Dedicated 5-GHz radio; 5 GHz, peak gain 5 dBi, internal antenna, omnidirectional in azimuth
External antenna (sold separately)	Cisco Catalyst 9120AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz); Cisco Catalyst 9120AXP Access Points) are certified for use with antenna gains up to 13 dBi (2.4 GHz and 5 GHz) with the AIR-ANT2513P4M-N= antenna; Cisco offers the industry's broadest selection of; antennas, delivering optimal coverage for a variety of deployment scenarios; Supports …
Smart antenna connector	Available on the 9120AXE and 9120AXP only; Compact multi-RF connector with DART interface; Requires the AIR-CAB002-DART-R= 2 ft smart antenna connector when used with antennas with RP-TNC connector; Required when running the flexible radio as either a second 5-GHz serving radio or a Wireless Security Monitoring radio
Arayüzler	1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz; o Auto-MDIX support; Management console port (RJ-45); USB 2.0 @ 4.5W
Boyutlar (W x L x H)	Access point (without mounting brackets): C9120AXI: 8.5 x 8.5 x 1.7” (21.6 x 21.6 x 4.3 cm), C9120AXE and C9120AXP: 8.5 x 8.05 x 2.0” (21.6 x 21.6 x 5.1 cm)
Ağırlık	Cisco Catalyst 9120AXI; 2.87 lb (1.3 kg); Cisco Catalyst 9120AXE/P; 3 lb (1.36 kg)
Input power requirements	802.3at Power over Ethernet Plus (PoE+), 802.3bt Cisco Universal PoE (Cisco UPOE+, Cisco UPOE); 802.3af PoE; Cisco power injector, AIR-PWRINJ6= (Note: This injector supports only 802.3at); Cisco power injector, AIR-PWRINJ5= (Note: This injector supports only 802.3af)
Ortam Koşulları	Cisco Catalyst 9120AXI; Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C); Nonoperating (storage) altitude test: 25˚C, 15,000 ft.; Operating temperature: 32° to 122°F (0° to 50°C); Operating humidity: 10% to 90% (noncondensing); Operating altitude test: 40˚C, 9843 ft.; Note: When the ambient operating temperature exceeds 40°C, the access point will shift from 4x4 to 2x2 on both the …
System memory	2048 MB DRAM; 1024 MB flash
Data rate, transmit power, receive sensitivity	For more detailed information about data rate, transmit power, and receive sensitivity, please refer to the Cisco RF details.
Desteklenen Kablosuz Kontrolcüler	Cisco Catalyst 9800 Series Wireless Controllers; Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
Indicators	Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors

Genel bakış

Cisco C9120AXI kullanım alanları ve özellikleri.

Cisco C9120AXI, Catalyst 9120 serisinden Wi-Fi 6 iç ortam kullanım için tasarlanmış kurumsal access point cihazıdır.

The Cisco Catalyst 9120AX Series Access Points are the next generation of enterprise access points. They are resilient, secure, and intelligent.

We are more dependent on our wireless networks than ever before. Additional devices connect to the network every year, and the Cisco Catalyst 9120AX Series Access Points will provide a seamless experience anywhere for everyone. Going beyond the Wi-Fi 6 (802.11ax) standard, the 9120AX Series provides integrated security, resiliency, and operational flexibility as well as increased network intelligence.

Öne Çıkan Özellikler

Wi-Fi 6 standardı
Kullanım: İç Ortam
Wi-Fi 6 (802.11ax)
Cisco RF ASIC
Uplink/downlink OFDMA
MU‑MIMO technology
BSS coloring
Target wake time
Intelligent Capture
Flexible Radio Assignment
Dual 5-GHz radio support
Smart antenna connector

Nerelerde kullanılır?

Ofis, otel, okul ve mağazalarda kesintisiz kablosuz kapsama ve dolaşım (roaming) için tavan veya duvar montajıyla kullanılır.

Tüm özellikler

Wi-Fi 6 standardı
Kullanım: İç Ortam
Wi-Fi 6 (802.11ax)
Cisco RF ASIC
Uplink/downlink OFDMA
MU‑MIMO technology
BSS coloring
Target wake time
Intelligent Capture
Flexible Radio Assignment
Dual 5-GHz radio support
Smart antenna connector
Cisco Embedded Wireless Controller
Application Hosting on Catalyst 9100 Access
Multigigabit Ethernet support
Bluetooth radio

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Catalyst 9120 Datasheet (EN)PDF · C9120AXI Catalyst 9120 Datasheet (PDF)PDF · C9120AXI

Sık sorulanlar

C9120AXI hakkında kısa yanıtlar.

C9120AXI fiyatı ne kadar?

C9120AXI için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
